Product Page

AERA INFLEX CYLINDER

Surface, Pendant

The Aera 3" and 4" Inflex Cylinders feature adjustable optics that can tilt 35 degrees and rotate 355 degrees, all while their cylindrical housings stay in their fixed position. Mountable as pendant or surface fixtures, they can serve to subtly emphasize certain features of a space or add visual interest to plain lighting design.

SPECIFICATIONS

SIZE: DIAMETER: 3", 4"

CERTIFICATIONS: Declare

CHROMATICITY: STATIC WHITE, FULL SPECTRUM, SOLA CHROMAWERX, DUO CHROMAWERX

LIGHT DISTRIBUTION: DIRECT

MOUNTING: PENDANT, SURFACE

OPTICS: XPoint™



OPTICS

Our advanced XPoint™ Refraction Technology uses micro optical paths that direct the light emitted from the COB (Chip On Board) to intersecting paths that meet in the center and disperse light in a precise direction for each beam angle. XPoint™ technology creates soft well lit environments that have strong visual comfort.

CHROMAWERX

ChromaWerx Sola is single-channel control that dims output while warming the color temperature in a pre-determined relationship. A simple digital or analog control sends a common signal to dual output digital drivers, which are programmed to adjust a specially populated LED array to emulate the effect of dimming a filament source. Dimming range is programmable but the default option runs from 3500K at 100% of full power to 2700K at 5% of full power.

ChromaWerx Duo is two-channel control. It uses analog or digital protocols for synchronous control of both warm and cool LED arrays, enabling the user to set color temperature and light output. Commonly called “tunable white”, ChromaWerx two-channel control provides the range of warm (2700K) to cool (6500K) color that can be useful for helping to entrain circadian rhythms, stimulate alertness for improved educational and work productivity, and compensate for jet lag, among other applications. The ChromaWerx drivers are programmed to limit maximum light output and power usage across all color temperatures.

PoE

PoE technology can be integrated into many of Lumenwerx’s lighting solutions and product families. For nodes, we always aim for complete integration, but when space is limited, we look for a remote solution that doesn’t compromise the design aesthetic. PoE can be integrated into 95% of our product offering, including our Chromawerx solutions.

See PoE webpage
