AERA 4" DOWNLIGHT

Downlight, Adjustable Downlight, Wall Wash, Multi-aperture

Aera downlights and multi-apertures (round and square) are designed with a sleek minimalist esthetic and true-to-size precision. Available in fixed, adjustable, and wall wash configurations, they are suitable additions to any interior space requiring illumination with outstanding optical performance (up to 113 lm/W), an industry-leading UGR of <10 for all beams, and a quiet ceiling effect, among many other features.

SPECIFICATIONS

SIZE: Shapes - ROUND, SQUARE

LIGHT SOURCE: LED

LIGHT DISTRIBUTION: DIRECT, WALL WASH, ADJUSTABLE

CHROMATICITY: STATIC WHITE, FULL SPECTRUM, SOLA CHROMAWERX, DUO CHROMAWERX

MOUNTING: DOWNLIGHTS, MULTI-APERTURES, RECESSED

SHAPE: ROUND, SQUARE

OPTICS: XPoint™



OPTICS

Our advanced XPoint™ Refraction Technology uses micro optical paths that direct the light emitted from the COB (Chip On Board) to intersecting paths that meet in the center and disperse light in a precise direction for each beam angle. Not only does the optic have excellent performance, but it also has zero spill light when illumination exits the bevel or trim of the downlight or cylinder. XPoint™ technology creates soft well lit environments that have strong visual comfort.

CHROMAWERX

Chromawerx Sola is single-channel control that dims output while warming the color temperature in a pre-determined relationship. A simple digital or analog control sends a common signal to dual output digital drivers, which are programmed to adjust a specially populated LED array to emulate the effect of dimming a filament source. Two color temperature range options are offered: 3000K to 1800K, and 2700K to 1800K. CRI is maintained above 80 throughout the dimming range.

Chromawerx Duo is two-channel control. It uses analog or digital protocols for synchronous control of both warm and cool LED arrays, enabling the user to set color temperature and light output. Commonly called “tunable white”, Chromawerx two-channel control provides the range of warm to cool color that can be useful for helping to entrain circadian rhythms, stimulate alertness for improved educational and work productivity, and compensate for jet lag, among other applications. Two color temperature range options are offered: 6500K to 2700K, and 5000K to 2700K. The Chromawerx drivers are programmed to limit maximum light output and power usage across all color temperatures. CRI is maintained above 80.

PoE

PoE technology can be integrated into many of Lumenwerx’s lighting solutions and product families. For nodes, we always aim for complete integration, but when space is limited, we look for a remote solution that doesn’t compromise the design aesthetic. PoE can be integrated into 95% of our product offering, including our Chromawerx solutions.
