VIA 3 SEAL PERIMETER

Direct

The Via 3 Seal Perimeter creates a compact and continuously illuminated opening at the wall/ceiling intersection. The luminaire installs in grid or drywall ceilings in a choice of three arrangements: level with the ceiling plane, with a shallow 1" regress above the ceiling, and with a deep 3 ¼" regress. Via 3 Seal Perimeter is gasketed and sealed polycarbonate clear lens.

  • Three mounting positions
  • Lit corners available
  • Wet Suitable (IP54)

SPECIFICATIONS

SIZE: 3 1/32" x 3 3/4" - 3 1/32" x 4 3/4" - 3 1/32" x 7"

LIGHT SOURCE: LED

CHROMATICITY: STATIC WHITE, FULL SPECTRUM, SOLA CHROMAWERX, DUO CHROMAWERX

APPLICATIONS: HEALTHCARE

COLOR TEMPERATURE: 2700k, 3000k, 3500k, 4000k, 6500k

MOUNTING: RECESSED

LIGHT DISTRIBUTION: PERIMETER

OPTICS: EPDO



OPTICS

Environmentally Protected Direct Optic (EPDO) The Environmentally Protected Direct Optic creates a seal that blocks debris and moisture, and withstands UV distortion and moderate impact. This extruded snap-in lens has a gasket to ensure proper sealing. The lens is 1/16" thick and made of frosted polycarbonate. Internally, white, side kicking reflectors guide the light through the lens. The EPDO suits moderate climate environments.

CHROMAWERX

ChromaWerx Sola is single-channel control that dims output while warming the color temperature in a pre-determined relationship. A simple digital or analog control sends a common signal to dual output digital drivers, which are programmed to adjust a specially populated LED array to emulate the effect of dimming a filament source. Dimming range is programmable but the default option runs from 3500K at 100% of full power to 2200K at 5% of full power. CRI is maintained above 80 throughout the dimming range.

ChromaWerx Duo is two-channel control. It uses analog or digital protocols for synchronous control of both warm and cool LED arrays, enabling the user to set color temperature and light output. Commonly called “tunable white”, ChromaWerx two-channel control provides the range of warm (2700K) to cool (6500K) color that can be useful for helping to entrain circadian rhythms, stimulate alertness for improved educational and work productivity, and compensate for jet lag, among other applications. The ChromaWerx drivers are programmed to limit maximum light output and power usage across all color temperatures. CRI is maintained above 80.

PoE

PoE technology can be integrated into many of Lumenwerx’s lighting solutions and product families. For nodes, we always aim for complete integration, but when space is limited, we look for a remote solution that doesn’t compromise the design aesthetic. PoE can be integrated into 95% of our product offering, including our Chromawerx solutions. See PoE webpage

Performance
Cross section
