PIVOT

Pendant, Surface, Recessed

Pivot is an architectural linear magnetic track lighting system for pendant, recessed, and surface mounting. Modular and expandable, it is composed of 17+ modules to mix and match, including linear, track head, and cylinder fixtures. Offered as a Direct or Direct/Indirect system, Pivot has the flexibility to answer a wide variety of lighting applications, from general to accent to wall wash, with the adaptability to change it up with a simple click of a magnet.

  • 17+ modules
  • 48V track
  • Pendant, recessed or surface mounting
  • Tool-free magnetic modules
  • Secure locking mechanism
  • Track connectors for patterns and shapes
  • Integral drivers (recessed and pendant systems)
  • Remoted  drivers (surface systems)
  • Up to 1000 lm/ft
  • 1.55" wide
  • Direct or Direct/Indirect distribution
  • Direct: modules or blanks
  • Indirect: Wide Indirect Optic (WIO) or blanks
  • Variety of controls

SPECIFICATIONS

LIGHT SOURCE: LED

LIGHT DISTRIBUTION: DIRECT, DIRECT/INDIRECT, WIDESPREAD

COLOR TEMPERATURE: 2700k, 3000k, 3500k, 4000k

CHROMATICITY: STATIC WHITE, FULL SPECTRUM

MOUNTING: CYLINDER-CUBOID, DOWNLIGHTS, PENDANT, RECESSED, SURFACE, WALL-RECESSED

OPTICS: HLO, IRO™, MRO, REF, SOF, WIO2, WRO



OPTICS

DIRECT

High-Efficiency Lambertian Optic (HLO)

Shielding of diffusing 0.075" thick acrylic provides up to 88% transmission and good obscuration. Matte white reflectors distribute LED output across the shielding. Luminaire brightness is controlled by the ratio of luminous flux to shielding area. HLO is available as a flush diffuser or as a drop diffuser extending 0.5" or 1.5" below the luminaire housing. Drop diffusers are extruded with glued end caps. HLO optics have a spacing crtieria of 1.12.

Wall Wash Optic (WW)

Wall Wash optics use multiple mid-flux emitters in a continuous array, supported by an angled board. An aluminum reflector collects and redirects emitter flux, while a refractive film adjusts both vertical and horizontal intensity and eliminates source image. The result is excellent uniformity up and down the wall, as well as between luminaires.

Soft-Edged Feathered Beam (SOF)

The Soft-Edged Feathered Beam blends the light into darker areas for a gentle brightness transition. Each LED emitter directs light through a single, custom molded circular optic using total internal reflection (TIR) to shape the light. A 0.5" reflective square louver provides a cut off with a UGR of 10. Three different TIR elements create a choice of beam spread: 25º narrow flood (NFL), 35º flood (FLD), or 55º wide flood (WFL).

Sharp-Edged Cut-Off Beam (REF)

The Sharp-Edged Cut-Off Beam creates dramatic impact, limiting the spread of light outside of the primary beam. A molded conical reflector redirects light from each emitter into the desired beam angle. A 0.5" reflective square louver provides a cut off with a UGR of 10. Three different TIR elements create a choice of beam spread: 15º spot (SPT), 30º flood (FLD), or 45º wide flood (WFL).

Isotropic Radiant Optic™ (IRO™)

The Isotropic Radiant Optic™ is a spherical lens designed with a spike-textured surface through which light rays are diffused outward and equally in all directions.

INDIRECT

Widespread Indirect Optic (WIO2)

A horizontal LED array with a widespread indirect micro prismatic optic that offers an impressive 160° spread. WIO2 creates an even illumination for smooth brightness on the ceiling that can achieve uniformity ratios of up to 2:1.
