Product Page

VOILA SEAL

Direct

Voila Seal is a new class of downlights, featuring precision optics, outstanding quality of light, and robust, user-friendly construction for Healthcare spaces.

  • Gasketed and sealed trim meeting IP54
  • 8 beam angles
  • Easy-to-clean unit with antimicrobial finish
  • Multiple control options

SPECIFICATIONS

SIZE: 4"

LIGHT SOURCE: LED

LIGHT DISTRIBUTION: DIRECT

CHROMATICITY: STATIC WHITE, DUO CHROMAWERX, SOLA CHROMAWERX

APPLICATIONS: HEALTHCARE

MOUNTING: DOWNLIGHTS, RECESSED

COLOR TEMPERATURE: 2700k, 3000k, 3500k, 4000k, 6500k

OPTICS: HYFLEX



OPTICS

Hyflex optics provide precise optical control in a remarkably compact form. The core of this four-tier system is compound reflector with a central TIR element, just 1.06" deep. Beam-smoothing discs perfect beam angles up to 90º. Beam angles are easily interchanged in the field.

CHROMAWERX

ChromaWerx Sola is single-channel control that dims output while warming the color temperature in a pre-determined relationship. A simple digital or analog control sends a common signal to dual output digital drivers, which are programmed to adjust a specially populated LED array to emulate the effect of dimming a filament source. Dimming range is programmable but the default option runs from 3500K at 100% of full power to 2200K at 5% of full power. CRI is maintained above 80 throughout the dimming range.

ChromaWerx Duo is two-channel control. It uses analog or digital protocols for synchronous control of both warm and cool LED arrays, enabling the user to set color temperature and light output. Commonly called “tunable white”, ChromaWerx two-channel control provides the range of warm (2700K) to cool (6500K) color that can be useful for helping to entrain circadian rhythms, stimulate alertness for improved educational and work productivity, and compensate for jet lag, among other applications. The ChromaWerx drivers are programmed to limit maximum light output and power usage across all color temperatures. CRI is maintained above 80.

PoE

PoE technology can be integrated into many of Lumenwerx’s lighting solutions and product families. For nodes, we always aim for complete integration, but when space is limited, we look for a remote solution that doesn’t compromise the design aesthetic. PoE can be integrated into 95% of our product offering, including our Chromawerx solutions. See PoE webpage
